PoE M.2 Module
Precision Power Control
The PSU M.2 Module delivers finely tuned power across two independent channels, each programmable for voltage and current with hardware-level protection. Whether you’re powering sensitive components or driving demanding loads, its soft-start and set-point accuracy ensure stable and predictable performance.
Built for Integration
Designed to slot seamlessly into the Accordion Agent ecosystem, this compact power supply module brings high-output capability in a space-efficient form factor. Engineers can rely on its M.2 interface for straightforward integration without compromising on control or safety.
Intelligent Protection
With hardware over/under voltage protection and configurable overcurrent safeguards, the PSU M.2 Module protects both your system and your workflow. Voltage and current measurement accuracy within ±0.5% and ±1.5% respectively ensures dependable diagnostics and monitoring.
Flexible Output Performance
Each channel supports up to 18 V and 10 A, with a total output power of 60 W. Power derating is intelligently managed, and a maximum voltage drop of 0.7 V keeps delivery consistent even under load.
Specifications
Article data
| Article number | ESH10000533 |
| Part name | M.2 PSU Module 2 Channel |
General
| Total Channels | 2 |
| Total output power | 60 W |
Per Channel
| Output Voltage | 0 – 18 V |
| Output Current | 10 A, Power derated |
| Max Voltage drop | 0,7 V |
| Start | Soft-start |
| Set-point Accuracy | -0,5% – 0,5% |
| Voltage measurement accuracy | -0,5% – 0,5% |
| Current measurement accuracy | -1,5% – 1,5% |
| Voltage Protection | Hardware Over/Under |
| Overcurrent protection | Hardware |
